6-Element Tubular Metal Over The Side (6HS) Immersion Heater

Steel, 316 & 304 Stainless Steel

Durable, efficient chemical heater.

Features
• Heavy wall metal sheaths available in 316 stainless steel
• Watt densities up to 40 watts/square inch (6.2 w/cm²).
• Vapor resistant, flame retardant polypropylene terminal enclosure with 3 ft (.9m) flexible PVC liquid tight conduit.
• Grounded construction and built in thermal protector. Replaceable P1 protector standard for solutions up to 180°F(82°C).
• Certification: cULus (excludes 600 volts)

Specifications
• 6000 - 21000 watts
• 208 to 600 volts

Options available (consult factory)
• Resettable thermal protectors
• All metal terminal enclosures.
• Custom configurations and lengths
• Custom wire and conduit lengths

Downloads

6HS Immersion Heater
